Suction Tile Lifter - Tile Lifter vacuum LABORA

LABORA suction tile lifter or tile lifter for easily and ergonomically lifting tiles.

LABORA vacuum suction tile lifter or tile lifter made of powder-coated steel, with a height of 72 cm, equipped with a 50 cm wide grip, a 30 cm canvas-reinforced Vredestein tire and a sturdy EPDM ring.

With the LABORA suction tile lifter, tiles can be laid or moved manually, with a maximum lifting weight of approx. 30 kilos. The suction tile lifter works best on clean, flat tiles. On porous surfaces, there is usually insufficient grip.

The LABORA suction tile lifter is popular with pavers, landscapers and brick pavers.

The wide grip is equipped with comfortable handles that provide a good grip while lifting. The strong EPDM ring on the underside ensures a perfect seal against the surface and thus good suction power. If worn or damaged, the EPDM ring can be replaced.

By using the LABORA suction tile lifter, it is possible to lift tiles in an ergonomic way. In addition, the suction tile lifter is ideal for repositioning tiles on a roof garden or roof terrace, without damaging the surface or roofing membrane.

Instructions for use suction tile lifter - tile lifter

-Place the suction tile lifter with the ring on the tile
-Push air out of the tire by pressing the suction tile lifter downward
-Place a thumb on the hole in the grip to create a vacuum
-Lift the suction tile lifter with both hands, keeping your thumb on the hole
-Place the tile in the desired location and remove your thumb from the hole

The further you press the tire downward, the more vacuum you generate and the heavier you can lift.
